Oracle 19c Flashback Technology (5/7): FLASHBACK_TRANSACTION_QUERY

When working with Flashback Transaction Query in Oracle 19c, retrieving the UNDO_SQL column is essential if you want to reverse DML operations (INSERT, UPDATE, DELETE) manually.

This article explains:

1. What FLASHBACK_TRANSACTION_QUERY is
2. Why UNDO_SQL may not appear
3. How to enable the required logging
4. How to correctly retrieve UNDO_SQL
5. Troubleshooting tips

1. What is FLASHBACK_TRANSACTION_QUERY?

FLASHBACK_TRANSACTION_QUERY is a data dictionary view that shows historical transaction information stored in UNDO.

It provides:

• XID (Transaction ID)
• START_TIMESTAMP
• COMMIT_TIMESTAMP
• OPERATION (INSERT/UPDATE/DELETE)
• TABLE_NAME
• UNDO_SQL (SQL to reverse the change)

This feature depends on:

• UNDO retention
• Supplemental logging
• Sufficient UNDO data still available

2. Why UNDO_SQL May Be NULL or Not Displayed

Common causes:

2.1. Supplemental logging not enabled

Without supplemental logging, Oracle does not log enough information to reconstruct the undo statement.

2.2. UNDO data aged out

If UNDO_RETENTION is too small, the undo information may be overwritten.

2.3. Querying wrong user / PDB

In multitenant (CDB/PDB), you must query inside the correct PDB.

3. Enable Supplemental Logging (Required on CDB$ROOT in CDB/PDB)

To retrieve proper UNDO_SQL, enable supplemental logging at database level:

select supplemental_log_data_min from v$database;
NO

ALTER DATABASE ADD SUPPLEMENTAL LOG DATA;

To verify:

SELECT supplemental_log_data_min FROM v$database;

It should return:

YES

4. Example Scenario

We update an employee salary and commit.

Step 1 – Check Original Salary

SQL> select salary from empv3 where employee_id=100;
SALARY
----------
     24003

Step 2 – Perform UPDATE

SQL> update empv3 set salary = salary*1.15 where employee_id=100;
1 row updated.
SQL> commit;
Commit complete.

Step 3 – Verify New Salary

SQL> select salary from empv3 where employee_id=100;
SALARY
----------
  27603.45

Now we want to reverse this change using FLASHBACK_TRANSACTION_QUERY.

5. Important Requirements Checklist

Requirement	Check Command
Supplemental Logging	SELECT supplemental_log_data_min FROM v$database;
UNDO Retention	SHOW PARAMETER undo_retention
Enough UNDO Space	SELECT tablespace_name, bytes FROM dba_data_files WHERE tablespace_name LIKE '%UNDO%';
Correct PDB	SHOW CON_NAME;

6. UNDO_SQL Is Still not NULL

Check the result of the

SELECT distinct xid, operation, logon_user, start_timestamp, commit_timestamp,  undo_sql FROM flashback_transaction_query WHERE table_name = 'EMPV3' ORDER BY commit_timestamp DESC;

XID              OPERATION                        LOGON_USER START_TIMESTAMP     COMMIT_TIMESTAMP
---------------- -------------------------------- ---------- ------------------- -------------------
UNDO_SQL
-----------------------------------------------------------------------------
08001E00B6030000  UPDATE   HR  01-09-2025 17:37:31  01-09-2025 17:37:34
update "HR"."EMPV3" set "SALARY" = '24003' where ROWID = 'AAAR4uAAEAAAKbrAAA';

0900210055030000  UNKNOWN  HR  01-09-2025 17:33:13  01-09-2025 17:33:43

7. Summary

To retrieve UNDO_SQL:

1. Enable supplemental logging
2. Ensure UNDO retention is sufficient
3. Query FLASHBACK_TRANSACTION_QUERY
4. Filter UNDO_SQL IS NOT NULL
5. Make sure you’re in the correct PDB
